Teledyne iTrans 2 Infrared Gas Detector, Explosion proof w/ On-Board Relays – Carbon Monoxide (CO) 0-999 PPM

Description

The iTrans 2 Infrared Gas Sensor employs an intelligent electronics platform to provide one or two points of detection from a single head. With the optional HART Communication Protocol, the iTrans 2 offers remote diagnostics, set-up or calibration. The iTrans 2 is able to detect any combination of gases for a specific environment and boasts a wide range of safety features including automatic sensor recognition, access code security and zero and cal fault protectionFeaturesThe optional HART communication protocol for the iTrans 2 offers remote diagnostics, set-up or calibration by super-imposing a digital current across the industry standard 4-20mA analog lineWide sensor offering including electrochemical, catalytic bead and infrared sensors are all supported for the iTrans 2An optional stainless steel enclosure is available for use in corrosive environmentsDual-channel, split-screen LED display for optimal visibility in dark placesA simple magnetic wand can be used for full transmitter configuration and calibration without opening the unit’s explosion-proof housingUp to two gases can be detected and displayed on the iTrans 2. Both sensors may be mounted directly to the transmitter or mounted remotelySmart sensors come pre-calibrated and automatically send sensor information, such as sensor life, to the transmitter. A sensor life indicator is displayed immediately after each calibrationApprovals: NRTL/c and CSA, ATEX, IECEx,China ExSpecificationsBrand: TeledyneSeries: iTrans2Part Number: iTrans2-11010Sensor: ElectrochemicalMaterial (Housing): Epoxy Coated AluminumCertifications / Approvals: – CCSAUS*: Class I, Div 1, Groups B, C, D., Ed IIB + H2 T5, AEd llB + H2T5, Class I, Div 2, Groups A, B, C, D.; ATEX and IECEx: II 2G – Edb IIB + H2 T5 Gb; NEPSI: GYB15.1621X – Ed IIB + H2 T5 Gb GB15322.1-2003 Fire protection; INMETRO: Edb IIB+H2 T5 GbDisplay: Dual-channel split-screen LED displayGas: CO (0-999ppm)***Ingress Protection: NEMA 4X, IP66Alarm Relays: 3 alarm relaysInput Voltage: 24V DCOperating Humidity Range: 10-90% RH (non-condensing)Output Signal: + RS-485 Modbus (9600 baud)Relay Type: Modbus On-Board RelaysResponse Time: T50: < 10 seconds (catalytic methane - T90: <30 Seconds)Temperature Range: -40°C to +75°C (-40°F to +167°F)Type: Explosion proof/ On-BoardApplicationsOil &Gas IndustryOffshore DrillingUtilities and PowerPetrochemical IndustryMunicipal Water and Waste TreatmentFood & Beverage ProductionDownloadsSpecification Sheet (PDF Download)Product Manual (PDF Download)Product Literature (PDF Download)
