Superklean Duraflow DM150S Series Stainless Steel Mini Spray Nozzles
Description
SuperKleans DuraFlow mini spray nozzle is specifically designed as an industrial LIGHTWEIGHT spray nozzle with heavyweight performance. Its unique design allows the convenience of approximately half of the weight of its bigger brother, the high flow DuraFlow nozzle. Its cover design is not only durable, but also protects the user from hot surfaces produced by high temperature washdown applications. The DuraFlow mini reduces hand fatigue and offers smooth lever action. Variable spray patterns, adjustable from fan spray to solid stream, is one of the many features offered by the new SuperKlean DuraFlow mini spray nozzle. Water conservation is assured upon release of lever by the drip-free automatic shutoff feature. Features Small compact design Light weight versus other designs Fully insulated Specifications Material: 304 stainless steel Weight: 0.77 lbs. Rating: 150 PSI/200° F (93° C) Maximum Tested Operating Pressure: 500 PSI Do not connect nozzle directly to live steam Contents Standard High Flow Inlet Pressure Flow Rate Inlet Pressure Flow Rate *(PSIG) *(GPM) *(PSIG) *(GPM) 25 2.93 25 4.39 50 3.86 50 6.54 75 4.91 75 8.18 100 5.78 100 9.56 125 6.71 125 10.83 150 7.19 150 11.89 * Estimated Standard flow rates can be achieved with the purchase of a flow restrictor adapter
