Dixon HAB100EZ 1 in. Cam & Groove Hastelloy Type B Coupler – Male NPT

Description

The Dixon HAB100EZ Cam & Groove Type B Coupler Male NPT is designed for secure and efficient liquid transfer applications. Constructed from Hastelloy® CW12MW with EZ Boss-Lock™ cam arms, it offers superior corrosion resistance and durability. This 1 in. coupler ensures a reliable seal with FKM-A gaskets and stainless steel components, supporting safe operation at up to 250 PSI. Ideal for demanding industrial environments, it provides a quick, tool-free connection compatible with A-A-59326D standards. Features Made from Hastelloy® CW12MW for exceptional corrosion resistance. EZ Boss-Lock™ cam arms constructed from 316 stainless steel with 303 stainless steel pins. Trivalent chrome plated 12 gauge steel rings for added durability. Supplied with FKM-A gasket for secure sealing. Quick, tool-free connection with hand pressure on cam levers. Interchangeable with Commercial Item A-A-59326D. Specifications Size: 1 in. Material: Hastelloy® CW12MW Cam Arm Material: 316 Stainless Steel Pin Material: 303 Stainless Steel Seal: FKM-A Maximum Operating Pressure: 250 PSI Weight: 1.156 lbs. Connection Type: Type B Coupler Male NPT Applications: Designed for use with liquids (consult Dixon for specific recommendations) Note: Not for use with compressed air or steam service DownloadsSpecification Sheet (PDF Download)
