Dixon Breaking Bolt Series Aluminum 150# Flange x 150# Flange Safety Break-Away Coupling

Description

Coupling is designed to minimize spillage and damage associated with drive away and pull away incidents. Typically used for loading racks. The safety break-away valve consists of two halves, each with a valve that has an O-ring seal. When the safety break-away couplings separate, it allows the valves to close. The two valves close rapidly, minimizing exposure to personnel and the environment. Safety break-away couplings have three external break bolts. In the case of axial tension all of the bolts take up the force corresponding to the break force on the hose with a safety margin. Non-axial forces concentrate the tension forces more strongly on one bolt, so that the safety break-away coupling reacts in a natural way to the reduction of the hose break forces. Features Designed to be installed between a fixed point (pipe, pump, manifold) and a hose Coupling automatically senses an excessive load, closes the valves and disconnects High flow rate / low pressure drop Specifications Size: 2 – 6 in. MaWorking Pressure: 230 PSI Material: Aluminum Seal: FKM   Size     Flow Rate     Length     Width   2 in. 200 GPM 7 in. 4.5 in. 3 in. 650 GPM 8.5 in. 6.8 in. 4 in. 800 GPM 9 in. 9.3 in. 5 in. 1100 GPM 14 in. 10.6 in. 6 in. 1500 GPM 15.1 in. 12.5 in.
