Dixon 2 1/2 in. Face Lower Back Mount Stainless Panel Builder Gauges

Description

Dixon stainless steel panel gauges are designed to fit the industry standard 2.56 inch panel hole cutout. They are used in gaseous and liquid media suitable for corrosive environments. Features ASME B40.100 Grade A ± 2/1/2% full scale accuracy Figure interval: 3 Minor gradient: 0.2 316L stainless steel wetted parts materials 304 stainless steel case and ring White aluminum dial with black lettering; stop pin Black aluminum pointer Glycerin filled Laminated safety glass window lens Temperature Range: -4°F to 140°F (-20°C to 60°C) Dial Specs               SKU PSI Range Figure Interval Graduation Interval     DXPBLSS15 0-15 3 0.2     DXPBLSS30 0-30 5 0.5     DXPBLSS60 0-60 10 1     DXPBLSS100 0-100 20 2     DXPBLSS160 0-160 20 2     DXPBLSS200 0-200 50 5     DXPBLSS300 0-300 50 5     DXPBLSS400 0-400 100 10     DXPBLSS600 0-600 100 10     DXPBLSS800 0-800 200 20     DXPBLSS1000 0-1000 200 20     DXPBLSS1500 0-1500 300 20     DXPBLSS2000 0-2000 500 50     DXPBLSS3000 0-3000 500 50     DXPBLSS5000 0-5000 1000 100
