BelAire Iron Series 4G3HHL Truck Mount Two-Stage 30 Gallon Air Compressor w/Honda Engine & Electric Start, 13 HP

Description

BelAire Air Compressor’s Iron Series Compressors feature all cast iron design pumps. Models include simplecompressors up to 10hp and duplemodels from 10-20hp. Choose from our standard or ELITE (full featured) models. All Iron Series Compressors come with the 2 Year Bumper to Bumper Warranty with no additional purchase required.

Features

Two-stage truck mount air compressor is continuous duty where a power cord can’t reach. Built to handle the toughest situations.
13 HP Honda GX390 engine w/electric start for superior reliability and being exceptionally quiet. Lower noise levels, lower vibration and lower emissions.
Low oil alert offers maximum protection and less downtime.
Heavy-duty all cast iron pump adds dependability and smooth operation.
Finned coolers enable more efficient heat exchange
Automotive-style rod bearing & wrist pins allows less oil carry over
Space saving concentric valves offer compact design and madelivery volume
Sturdy and reliable air pressure whenever needed
Designed for service trucks & contractors running multiple tools
Slow down idle control reduces fuel consumption & extends engine life by controlling the engine’s idling rotational speed RPM
Pressure gauge shows regulated pressure of compressed air
Safety valves prevent pressure in tan from rising over limit
EZ pull tank drain makes tank maintenance simple & convenient. Routine draining prevents air contamination & prolongs tool life
100% factory tested at full pressure

Specifications

30 Gallon horizontal tank with 3/4 in. ball valve outlet
13 HP Honda GX engine with auto idle and 12V key start w/recoil and electric start
Fuel type=Gasoline
Pressure gauge
Air filter
Solid cast iron two-stage pump
23 CFM@100 PSI
Mapressure 175 PSI
Belt drive
Oil splash lubricated
Use 30 W Non Detergent Oil
Oil sight glass
45 in. L 19 in. W 43 in. H
ASME certified
2 Year bumper to bumper warranty

Downloads
Manual (PDF Download)
