Balcrank AODD Pivot Series UP10 1 in. Aluminum Diaphragm Pump

Description

The UP10 Pivot Series pump combines universal design with a unique frictionless Pivot-Shaft Air Valve to provide maximum performance and efficiency. The pump was designed for simplified cleaning and maintenance. All Pivot series pumps are designed for maximum fluid flow and reduced air consumption. The UP10 pump combines a conventional flow design with a pivoting air valve for increased reliability. This pump can transfer fluids up to 53 GPM. The pump can be used as a stand-alone pump for transfer applications or as a system pump for fluid distribution. Balcrank does not recommend pumping windshield wash or any other fluid below 100° flash point. Specifications Air inlet: 1/2 in FNPT Fluid inlet port: 1 in. FNPT Fluid Outlet Port: 1 in. FNPT MaFlow Rate: 53 GPM (200 LPM) Air Pressure Range: 20 to 100 PSI ( 1.5 to 8 bar) Body Material: Aluminum Recommended fluids: Anti-Freeze, Lubricants, Used Oil, Used Fluids and Hydraulic Oil Markets served: Car & Truck Dealers, Fleets, Lube Trucks, In-Plant Transfer, Mining & Construction, and Agriculture/Farm Recommended Applications: Medium to Large Volume Transfer, De-Watering and Fluid Evacuation Downloads Specifications (PDF Download) Manual (PDF Download)
