5HP 1PH 56Y 2P ODP 3450 230V AOL UL1081

Description

Product Information

Brand Century
Mfr # B238V1
Wright’s # CEN B238V1
Country of Origin MEX

Specifications

C Dim 13.37″
Electrical Type Permanent Split Capacitor, Single Or Dual Voltage
Enclosure ODP
Frame 56Y
Frequency 60 Hz
HP 5 HP
HP2 5 HP
Insulation Class B
kW 3.7kW
Material Rolled Steel
MaAmbient 50°C
Number of Poles 2
Number of Speeds 1
Overload Protection Thermally Protected
Phase 1
Rated Current 16.4
Rated Voltage 230
Rotation Counterclockwise Pump End
RPM 3450
Service Factor 1
Shaft Diameter 0.5″
Speed 3450
Starting Method
