3/4HP PSC 48Z OAO 3spd 1075 208-230V BM
Description
Product Information
Brand Leeson
Mfr # X010
Wright’s # LSN X010
Country of Origin MEX
Specifications
C Dim 10.5″
Electrical Type Permanent Split Capacitor
Enclosure Open Air Over
Full Load Efficiency 54
Frame 48Z
Frequency 60
HP 0.75 HP
HP2 0.75 HP
Insulation Class B
kW 0.56kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Ring – Extended Studs
Number of Poles 6
Number of Speeds 3
Overload Protection AOL
Phase 1
Rated Current 5.8-5.6
Rated Voltage 208-230V
Rotation Selective Counterclockwise
RPM 1075
Service Factor 1
Shaft Diameter 0.5″
Speed 1075
Starting Method
