3/4HP 3PH 143TC TEFC 1200 208-230/460V

Description

Product Information

Brand Leeson
Mfr # K1318
Wright’s # LSN K1318
Country of Origin MEX

Specifications

C Dim 12.56″
Electrical Type Three Phase
Enclosure Totally Enclosed Fan Cooled
Full Load Efficiency 76.1
Frame 143
Frequency 60
HP 0.75 HP
HP2 3/4 HP
Insulation Class B
kW 0.56kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Round
Overload Protection No Protection
Phase 3
Rated Current 2.9-2.8
Rated Voltage 208-230/460
Rotation Counterclockwise/Clockwise
RPM 1140
Service Factor 1.15
Shaft Diameter 0.88″
