3/4HP 1PH 56C TEFC 3600 115/208-230V NB

Description

Product Information

Brand Leeson
Mfr # G516
Wright’s # LSN G516
Country of Origin MEX

Specifications

C Dim 12.32″
Electrical Type Capacitor Start Induction Run
Enclosure Totally Enclosed Fan Cooled
Full Load Efficiency 66
Frame 56
Frequency 60
HP 0.75 HP
HP2 3/4 HP
Insulation Class B
kW 0.56kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Round
Overload Protection No Protection
Phase 1
Rated Current 10.6/5.3-5.3
Rated Voltage 115/208-230
Rotation Selective Counterclockwise
RPM 3450
Service Factor 1.15
Shaft Diameter 0.625″
Starting Method
