3/4HP 1PH 56C ODP 3600 115/230V AOL NB JP

Description

Product Information

Brand Leeson
Mfr # C1083A
Wright’s # LSN C1083A
Country of Origin MEX

Specifications

C Dim 13.47″
Electrical Type Capacitor Start Induction Run
Enclosure Drip Proof
Full Load Efficiency 69.5
Frame 56
Frequency 60
HP 0.75 HP
HP2 3/4 HP
Insulation Class B
kW 0.56kW
Material Rolled Steel
MaAmbient 50°C
Mounting Type Round
Overload Protection Automatic
Phase 1
Rated Current 13
Rated Voltage 115/230
Rotation Clockwise
RPM 3450
Service Factor 1.5
Shaft Diameter 0.63″
Starting Method
