3/4HP 1PH 56 TEFC 1800 115/230V

Description

Product Information

Brand Leeson
Mfr # EG276
Wright’s # LSN EG276
Country of Origin MEX

Specifications

C Dim 12.43″
Electrical Type Capacitor Start Capacitor Run
Enclosure Totally Enclosed Fan Cooled
Full Load Efficiency 72
Frame 56
Frequency 60
HP 0.75 HP
HP2 3/4 HP
Insulation Class B
kW 0.56kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Rigid Base
Overload Protection No Protection
Phase 1
Rated Current 9.0-8.8
Rated Voltage 100-120/200-240
Rotation Counterclockwise/Clockwise
RPM 1725
Service Factor 1.25
Shaft Diameter 0.63″
Starting Method
