2HP 3PH 56H ODP 1800 208-230/460V AOL

Description

Product Information

Brand Leeson
Mfr # K1418
Wright’s # LSN K1418
Country of Origin MEX

Specifications

C Dim 13.96″
Electrical Type Three Phase
Enclosure DP
Full Load Efficiency 81.8
Frame 56H
Frequency 60 Hz
HP 2 HP
HP2 2 HP
Insulation Class B
kW 1.5kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 1
Overload Protection Automatic
Phase 3
Rated Current 6.2-6.0,3.0
Rated Voltage 208-230/460
Rotation Counterclockwise/Clockwise
RPM 1725
Service Factor 1.15
Shaft Diameter 0.63″
Speed 1725
