2HP 1PH 56HZ ODP 1800 115/208-230V AOL

Description

Product Information

Brand Leeson
Mfr # CG381
Wright’s # LSN CG381
Country of Origin MEX

Specifications

C Dim 14.33″
Electrical Type Capacitor Start Capacitor Run
Enclosure DP
Full Load Efficiency 72
Frame 56HZ
Frequency 60 Hz
HP 2 HP
HP2 2 HP
Insulation Class B
kW 1.5kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Rigid Base
Number of Poles 4
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 22.0,10.9-11.0
Rated Voltage 115/208-230
Rotation Counterclockwise/Clockwise
RPM 1725
Service Factor 1.15
Shaft Diameter 0.88″
Speed 1725
Starting Method
