2HP 1PH 56H 2P DP 3450 115/208-230V AOL

Description

Product Information

Brand Leeson
Mfr # C1161
Wright’s # LSN C1161
Country of Origin MEX

Specifications

C Dim 11.9″
Electrical Type Capacitor Start Capacitor Run
Enclosure DP
Full Load Efficiency 75.5
Frame 56H
Frequency 60 Hz
HP 2 HP
HP2 2 HP
Insulation Class B
kW 1.5kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 2
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 19.6,10.4-9.8
Rated Voltage 115/208-230
Rotation Counterclockwise/Clockwise
RPM 3450
Service Factor 1.2
Shaft Diameter 0.63″
Speed 3450
Starting Method
