2HP 1PH 145T 4P DP 1740 115/208-230V

Description

Product Information

Brand Leeson
Mfr # I147
Wright’s # LSN I147
Country of Origin MEX

Specifications

C Dim 14.22″
Electrical Type Capacitor Start Capacitor Run
Enclosure DP
Full Load Efficiency 78.5
Frame 145T
Frequency 60 Hz
HP 2 HP
HP2 2 HP
Insulation Class B
kW 1.5kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 1
Overload Protection No Protection
Phase 1
Rated Current 21.0/11.3-10.5
Rated Voltage 115/208-230
Rotation Selective Counterclockwise
RPM 1740
Service Factor 1.15
Shaft Diameter 0.875″
Speed 1740
Starting Method
