1HP 3PH 56Y OAO 1140 200-230/460V AOL CF

Description

Product Information

Brand Leeson
Mfr # X502
Wright’s # LSN X502
Country of Origin MEX

Specifications

C Dim 15.06″
Electrical Type Squirrel Cage Induction Run
Enclosure OAO
Full Load Efficiency 75.5
Frame 56Y
Frequency 60 Hz
HP 1 HP
HP2 1 HP
Insulation Class H
kW 0.75kW
Material Rolled Steel
MaAmbient 70°C
Mounting Type Round Belly Band
Number of Poles 6
Number of Speeds 1
Overload Protection Automatic
Phase 3
Rated Current 4-4.2/2.1 & 3.8/1.9
Rated Voltage 200-230/460
Rotation Reversible
RPM 1140
Service Factor 1
Shaft Diameter 0.625″
Speed 1140 & 950
Starting Method
