1HP 3PH 56 4P DP 1725 208-230/460V

Description

Product Information

Brand Leeson
Mfr # K278
Wright’s # LSN K278
Country of Origin MEX

Specifications

C Dim 10.88″
Electrical Type Three Phase
Enclosure DP
Full Load Efficiency 77.4
Frame 56
Frequency 60 Hz
HP 1 HP
HP2 1 HP
Insulation Class B
kW 0.75kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 1
Overload Protection No Protection
Phase 3
Rated Current 3.6-3.8,1.9
Rated Voltage 208-230/460
Rotation Counterclockwise/Clockwise
RPM 1725
Service Factor 1.15
Shaft Diameter 0.63″
Speed 1725
