1HP 3PH 56 4P DP 1725 208-230/460V AOL

Description

Product Information

Brand Leeson
Mfr # G100
Wright’s # LSN G100
Country of Origin MEX

Specifications

C Dim 11.47″
Electrical Type Squirrel Cage Induction Run
Enclosure DP
Full Load Efficiency 76.5
Frame 56
Frequency 60 Hz
HP 1 HP
HP2 1 HP
Insulation Class B
kW 0.75kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 1
Overload Protection Automatic
Phase 3
Rated Current 3.4-3.4/1.7 & 3.1/1.5-1.7
Rated Voltage 208-230/460
Rotation Reversible
RPM 1725
Service Factor 1.15
Shaft Diameter 0.625″
Speed 1725 & 1425
Starting Method
