1HP 3PH 145T 6P TEFC 1170 230/460V
Description
Product Information
Brand Leeson
Sub-Brand XRI® General Purpose
Mfr # E2102
Wright’s # LSN E2102
Country of Origin USA
Specifications
C Dim 13.75″
Electrical Type Squirrel Cage Induction Run
Enclosure TEFC
Full Load Efficiency 82.5
Frame 145T
Frequency 60 Hz
HP 1 HP
HP2 1 HP
Insulation Class F
kW 0.75kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Rigid Base
Number of Poles 6
Number of Speeds 1
Overload Protection No Protection
Phase 3
Rated Current 3.8/1.9 & 4/2
Rated Voltage 230/460
Rotation Reversible
RPM 1170
Service Factor 1.15
Shaft Diameter 0.875″
Speed 1170 & 975
Starting Method
