1HP 1PH 56Z 6P OE 1075 PSC 200-230/460V AOL CF

Description

Product Information

Brand Leeson
Mfr # P190
Wright’s # LSN P190
Country of Origin MEX

Specifications

C Dim 15.21″
Electrical Type Permanent Split Capacitor
Enclosure OE
Full Load Efficiency 68
Frame 56Z
Frequency 60 Hz
HP 1 HP
HP2 1 HP
Insulation Class B
kW 0.75kW
Material Rolled Steel
MaAmbient 65°C
Mounting Type Round
Number of Poles 6
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 6.7-6.8,3.4
Rated Voltage 200-230/460
Rotation Counterclockwise/Clockwise
RPM 1075
Service Factor 1
Shaft Diameter 0.63″
Speed 1075
