1HP 1PH 56C 2P TEFC 3450 115/208-230V WB

Description

Product Information

Brand Leeson
Mfr # D313
Wright’s # LSN D313
Country of Origin MEX

Specifications

C Dim 12.31″
Electrical Type Capacitor Start Induction Run
Enclosure TEFC
Full Load Efficiency 78.5
Frame 56C
Frequency 60 Hz
HP 1 HP
HP2 1 HP
Insulation Class B
kW 0.75kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Bolt-on Base
Number of Poles 2
Number of Speeds 1
Overload Protection No Protection
Phase 1
Rated Current 11.2/5.7-5.6
Rated Voltage 115/208-230
Rotation Selective Counterclockwise
RPM 3450
Service Factor 1.15
Shaft Diameter 0.625″
Speed 3450
Starting Method
