1HP 1PH 56 ODP 3600 115/230V AOL

Description

Product Information

Brand Leeson
Mfr # C180A
Wright’s # LSN C180A
Country of Origin MEX

Specifications

C Dim 12.33″
Electrical Type Capacitor Start Capacitor Run
Enclosure Drip Proof
Full Load Efficiency 80.5
Frame 56
Frequency 60
HP 1 HP
HP2 1 HP
Insulation Class B
kW 0.75kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Rigid Base
Overload Protection Automatic
Phase 1
Rated Current 8.8/4.4
Rated Voltage 115/230
Rotation Fixed Clockwise
RPM 3450
Service Factor 1.25
Shaft Diameter 0.625″
Starting Method
