1HP 1PH 56 ODP 1800 115/208-230V AOL

Description

Product Information

Brand Leeson
Mfr # C182A
Wright’s # LSN C182A
Country of Origin MEX

Specifications

C Dim 12.49″
Electrical Type Capacitor Start Capacitor Run
Enclosure Drip Proof
Full Load Efficiency 82.6
Frame 56
Frequency 60
HP 1 HP
HP2 1 HP
Insulation Class B
kW 0.75kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Rigid Base
Number of Poles 4
Number of Speeds 1
Overload Protection AOL
Phase 1
Rated Current 8.0/4.4-4.0
Rated Voltage 115/208-230V
Rotation Selective Counterclockwise
RPM 1725
Service Factor 1.15
Shaft Diameter 0.625″
Speed 1725
Starting Method
