1HP 1PH 56 4P DP 1725 115/230V

Description

Product Information

Brand Leeson
Mfr # S116
Wright’s # LSN S116
Country of Origin MEX

Specifications

C Dim 11.35″
Electrical Type Capacitor Start Induction Run
Enclosure DP
Full Load Efficiency 70
Frame 56
Frequency 60 Hz
HP 1 HP
HP2 1 HP
Insulation Class B
kW 0.75kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 1
Overload Protection No Protection
Phase 1
Rated Current 13.6/6.8
Rated Voltage 115/230
Rotation Selective Clockwise
RPM 1725
Service Factor 1
Shaft Diameter 0.625″
Speed 1725
Starting Method
