1HP 1PH 56 4P DP 1725 115/230V MOL PW

Description

Product Information

Brand Leeson
Mfr # C1480
Wright’s # LSN C1480
Country of Origin MEX

Specifications

C Dim 11.38″
Electrical Type Capacitor Start Induction Run
Enclosure DP
Full Load Efficiency 68
Frame 56
Frequency 60 Hz
HP 1 HP
HP2 1 HP
Insulation Class B
kW 0.75kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Rigid Base
Number of Poles 4
Number of Speeds 1
Overload Protection Manual
Phase 1
Rated Current 13.6,6.8
Rated Voltage 115/230
Rotation Counterclockwise/Clockwise
RPM 1725
Service Factor 1.15
Shaft Diameter 0.63″
Speed 1725
Starting Method
