1HP 1PH 56 4P DP 1725 115/208-230V AOL

Description

Product Information

Brand Leeson
Mfr # C1158
Wright’s # LSN C1158
Country of Origin MEX

Specifications

C Dim 11.38″
Electrical Type Capacitor Start Induction Run
Enclosure DP
Full Load Efficiency 70
Frame 56
Frequency 60 Hz
HP 1 HP
HP2 1 HP
Insulation Class B
kW 0.75kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 14.7,7.2-7.4
Rated Voltage 115/208-230
Rotation Counterclockwise/Clockwise
RPM 1725
Service Factor 1.15
Shaft Diameter 0.63″
Speed 1725
Starting Method
