1.5HP 3PH 6.5″ OAO 1140 208-230/460V AOL WB 56HZ CF

Description

Product Information

Brand Leeson
Mfr # X523
Wright’s # LSN X523
Country of Origin MEX

Specifications

C Dim 15.68″
Electrical Type Squirrel Cage Induction Run
Enclosure OAO
Full Load Efficiency 78.5
Frame 56HZ
Frequency 60 Hz
HP 1.5 HP
HP2 1-1/2 HP
Insulation Class H
kW 1.1kW
Material Rolled Steel
MaAmbient 70°C
Mounting Type Rigid Base
Number of Poles 6
Number of Speeds 1
Overload Protection Automatic
Phase 3
Rated Current 5.4-5.4/2.7 & 4.8/2.4
Rated Voltage 208-230/460
Rotation Reversible
RPM 1140
Service Factor 1
Shaft Diameter 0.625″
Speed 1140 & 950
Starting Method
