1.50HP 3PH 56C 2P DP 3450 208-230/460V NB

Description

Product Information

Brand Leeson
Mfr # K222
Wright’s # LSN K222
Country of Origin MEX

Specifications

C Dim 10.73″
Electrical Type Three Phase
Enclosure DP
Full Load Efficiency 77
Frame 56C
Frequency 60 Hz
HP 1.5 HP
HP2 1-1/2 HP
Insulation Class B
kW 1.1kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Round
Number of Poles 2
Number of Speeds 1
Overload Protection No Protection
Phase 3
Rated Current 5.0-4.8,2.4
Rated Voltage 208-230/460
Rotation Counterclockwise/Clockwise
RPM 3450
Service Factor 1.3
Shaft Diameter 0.63″
Speed 3450
