1.50HP 1PH 56H 4P DP 1725 115/208-230V MOL

Description

Product Information

Brand Leeson
Mfr # G951
Wright’s # LSN G951
Country of Origin MEX

Specifications

C Dim 12.44″
Electrical Type Capacitor Start Induction Run
Enclosure DP
Full Load Efficiency 77
Frame 56H
Frequency 60 Hz
HP 1.5 HP
HP2 1-1/2 HP
Insulation Class B
kW 1.1kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Rigid Base
Number of Poles 4
Number of Speeds 1
Overload Protection Manual
Phase 1
Rated Current 18.0/9.3-9.0
Rated Voltage 115/208-230
Rotation Selective Counterclockwise
RPM 1725
Service Factor 1.15
Shaft Diameter 0.625″
Speed 1725
Starting Method
