1/4HP 1PH 48Y ODP 1800 115/208-230V BM

Description

Product Information

Brand Leeson
Mfr # B313
Wright’s # LSN B313
Country of Origin MEX

Specifications

C Dim 9.95″
Electrical Type Capacitor Start Induction Run
Enclosure Drip Proof
Full Load Efficiency 57.5
Frame 48Y
Frequency 60
HP 0.25 HP
HP2 0.25 HP
Insulation Class B
kW 0.19kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base – Extended Studs
Number of Poles 4
Number of Speeds 1
Overload Protection AOL
Phase 1
Rated Current 5.2/2.8-2.6
Rated Voltage 115/208-230V
Rotation Selective Counterclockwise
RPM 1725
Service Factor 1.35
Shaft Diameter 0.5″
Speed 1725
Starting Method
