1/4HP 1PH 48 ODP 1800 115/230V AOL RB

Description

Product Information

Brand Leeson
Mfr # G1115
Wright’s # LSN G1115
Country of Origin MEX

Specifications

C Dim 9.57″
Electrical Type Capacitor Start Induction Run
Enclosure Drip Proof
Full Load Efficiency 55
Frame 48
Frequency 60
HP 0.25 HP
HP2 0.25 HP
Insulation Class B
kW 0.19kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 1
Overload Protection AOL
Phase 1
Rated Current 5.2,2.6
Rated Voltage 115/230V
Rotation Counterclockwise/Clockwise
RPM 1725
Service Factor 1.35
Shaft Diameter 0.5″
Speed 1725
Starting Method
