1/3HP 1PH 48Y TEAO 1200 208-230V AOL CF

Description

Product Information

Brand Leeson
Mfr # X297
Wright’s # LSN X297
Country of Origin MEX

Specifications

C Dim 8.06″
Electrical Type Permanent Split Capacitor
Enclosure Totally Enclosed Air Over
Full Load Efficiency 66
Frame 48
Frequency 60
HP 0.33 HP
HP2 1/3 HP
Insulation Class B
kW 0.25kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Round – Extended Studs
Overload Protection Automatic
Phase 1
Rated Current 1.9-1.8
Rated Voltage 208-230
Rotation Selective Counterclockwise
RPM 1075
Service Factor 1
Shaft Diameter 0.5″
Starting Method
