1/2HP 1PH 56 ODP 1800 115/208-230V AOL

Description

Product Information

Brand Leeson
Mfr # B317
Wright’s # LSN B317
Country of Origin MEX

Specifications

C Dim 10.32″
Electrical Type Capacitor Start Induction Run
Enclosure DP
Full Load Efficiency 66
Frame 56
Frequency 60 Hz
HP 0.5 HP
HP2 1/2 HP
Insulation Class B
kW 0.37kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base – Extended Studs
Number of Poles 4
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 8.0/4.1-4.0
Rated Voltage 115/208-230
Rotation Selective Counterclockwise
RPM 1725
Service Factor 1.25
Shaft Diameter 0.625″
Speed 1725
Starting Method
