1/2HP 1PH 5.6″ 4P OAO 1625 PSC 460V AOL CF

Description

Product Information

Brand Leeson
Mfr # X422
Wright’s # LSN X422
Country of Origin MEX

Specifications

C Dim 11.94″
Electrical Type Permanent Split Capacitor
Enclosure OAO
Full Load Efficiency 64
Frame 48Y
Frequency 60 Hz
HP 0.5 HP
HP2 1/2 HP
Insulation Class B
kW 0.37kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Round – Extended Studs
Number of Poles 4
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 1.7
Rated Voltage 460
Rotation Selective Counterclockwise
RPM 1625
Service Factor 1
Shaft Diameter 0.5″
Speed 1625
Starting Method
