0.75HP 3PH 56Y 6P OAO 1140 200-230/460V AOL CF

Description

Product Information

Brand Leeson
Mfr # X501
Wright’s # LSN X501
Country of Origin MEX

Specifications

C Dim 14.56″
Electrical Type Squirrel Cage Induction Run
Enclosure OAO
Full Load Efficiency 74
Frame 56Y
Frequency 60 Hz
HP 0.75 HP
HP2 3/4 HP
Insulation Class H
kW 0.56kW
Material Rolled Steel
MaAmbient 70°C
Mounting Type Round Belly Band
Number of Poles 6
Number of Speeds 1
Overload Protection Automatic
Phase 3
Rated Current 3.2-3.2/1.6 & 2.6/1.3
Rated Voltage 200-230/460
Rotation Reversible
RPM 1140
Service Factor 1
Shaft Diameter 0.625″
Speed 1140 & 950
Starting Method
