0.75HP 3PH 56 4P DP 1725 208-230/460V

Description

Product Information

Brand Leeson
Mfr # K277
Wright’s # LSN K277
Country of Origin MEX

Specifications

C Dim 10.88″
Electrical Type Three Phase
Enclosure DP
Full Load Efficiency 74
Frame 56
Frequency 60 Hz
HP 0.75 HP
HP2 3/4 HP
Insulation Class B
kW 0.56kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 1
Overload Protection No Protection
Phase 3
Rated Current 3.3-3.0,1.5
Rated Voltage 208-230/460
Rotation Counterclockwise/Clockwise
RPM 1725
Service Factor 1.25
Shaft Diameter 0.63″
Speed 1725
