0.75HP 3PH 56 4P DP 1725 208-230/460V AOL

Description

Product Information

Brand Leeson
Mfr # G101
Wright’s # LSN G101
Country of Origin MEX

Specifications

C Dim 10.97″
Electrical Type Squirrel Cage Induction Run
Enclosure DP
Full Load Efficiency 75.5
Frame 56
Frequency 60 Hz
HP 0.75 HP
HP2 3/4 HP
Insulation Class B
kW 0.56kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 1
Overload Protection Automatic
Phase 3
Rated Current 2.7-2.8/1.4 & 2.4/1.2-1.3
Rated Voltage 208-230/460
Rotation Reversible
RPM 1725
Service Factor 1.25
Shaft Diameter 0.625″
Speed 1725 & 1425
Starting Method
