0.75HP 1PH 56C 4P TEFC 1725 115/208-230V WB

Description

Product Information

Brand Leeson
Mfr # G572
Wright’s # LSN G572
Country of Origin MEX

Specifications

C Dim 12.31″
Electrical Type Capacitor Start Induction Run
Enclosure TEFC
Full Load Efficiency 70.5
Frame 56C
Frequency 60 Hz
HP 0.75 HP
HP2 3/4 HP
Insulation Class B
kW 0.56kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Bolt-on Base
Number of Poles 4
Number of Speeds 1
Overload Protection No Protection
Phase 1
Rated Current 11/5.4-5.5 & 11.4/5.7
Rated Voltage 115/208-230
Rotation Selective Counterclockwise
RPM 1725
Service Factor 1.15
Shaft Diameter 0.625″
Speed 1725 & 1425
Starting Method
