0.75HP 1PH 56 4P DP 2spd 1725 115V AOL

Description

Product Information

Brand Leeson
Mfr # C474
Wright’s # LSN C474
Country of Origin MEX

Specifications

C Dim 11.48″
Electrical Type Capacitor Start Capacitor Run
Enclosure DP
Full Load Efficiency 70
Frame 56
Frequency 60 Hz
HP 0.75 HP
HP2 3/4 HP
Insulation Class B
kW 0.56kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 2
Overload Protection Automatic
Phase 1
Rated Current 9.0,6.4
Rated Voltage 115
Rotation Counterclockwise/Clockwise
RPM 1725
Service Factor 1.25
Shaft Diameter 0.63″
Speed 1725/1140
Starting Method
