0.75HP 1PH 48Y 6P TEAO 1075 PSC 460V AOL CF

Description

Product Information

Brand Leeson
Mfr # X459
Wright’s # LSN X459
Country of Origin MEX

Specifications

C Dim 12.5″
Electrical Type Permanent Split Capacitor
Enclosure TEAO
Full Load Efficiency 68
Frame 48Y
Frequency 60 Hz
HP 0.75 HP
HP2 3/4 HP
Insulation Class B
kW 0.56kW
Material Rolled Steel
MaAmbient 60°C
Mounting Type Round – Extended Studs
Number of Poles 6
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 2.1
Rated Voltage 460
Rotation Selective Counterclockwise
RPM 1075
Service Factor 1
Shaft Diameter 0.5″
Speed 1075
Starting Method
