0.50HP 1PH 56 4P DP 2spd 1725 SpP 115V AOL

Description

Product Information

Brand Leeson
Mfr # H176
Wright’s # LSN H176
Country of Origin MEX

Specifications

C Dim 11.48″
Electrical Type Split Phase
Enclosure DP
Full Load Efficiency 64
Frame 56
Frequency 60 Hz
HP 0.5 HP
HP2 1/2 HP
Insulation Class B
kW 0.37kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 2
Overload Protection Automatic
Phase 1
Rated Current 8.0,4.2
Rated Voltage 115
Rotation Counterclockwise/Clockwise
RPM 1725
Service Factor 1.25
Shaft Diameter 0.63″
Speed 1725,1140
Starting Method
