0.50HP 1PH 48Z 4P TEAO 1625 PSC 208-230V AOL CF

Description

Product Information

Brand Leeson
Mfr # X468
Wright’s # LSN X468
Country of Origin MEX

Specifications

C Dim 11.75″
Electrical Type Permanent Split Capacitor
Enclosure TEAO
Full Load Efficiency 71.7
Frame 48Z
Frequency 60 Hz
HP 0.5 HP
HP2 1/2 HP
Insulation Class B
kW 0.37kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Round – Extended Studs
Number of Poles 4
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 2.9-2.6
Rated Voltage 208-230
Rotation Selective Counterclockwise
RPM 1625
Service Factor 1
Shaft Diameter 0.5″
Speed 1625
Starting Method
