0.33HP 3PH 56C 4P TENV 1725 208-230/460V WB

Description

Product Information

Brand Leeson
Mfr # G580
Wright’s # LSN G580
Country of Origin MEX

Specifications

C Dim 9.93″
Electrical Type Squirrel Cage Inverter Rated
Enclosure TENV
Full Load Efficiency 68
Frame 56C
Frequency 60 Hz
HP 0.33 HP
HP2 1/3 HP
Insulation Class F
kW 0.25kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Bolt-on Base
Number of Poles 4
Number of Speeds 1
Overload Protection No Protection
Phase 3
Rated Current 1.8-1.6/.8 & 1.5/.75
Rated Voltage 208-230/460
Rotation Reversible
RPM 1725
Service Factor 1.15
Shaft Diameter 0.625″
Speed 1725 & 1425
Starting Method
