0.33HP 1PH 56C 2P DP 3450 115/230V AOL NB

Description

Product Information

Brand Leeson
Mfr # J1025
Wright’s # LSN J1025
Country of Origin MEX

Specifications

C Dim 10.71″
Electrical Type Capacitor Start Induction Run
Enclosure DP
Full Load Efficiency 56.6
Frame 56C
Frequency 60 Hz
HP 0.33 HP
HP2 1/25 HP
Insulation Class B
kW 0.25kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Round
Number of Poles 2
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 6.4,3.2
Rated Voltage 115/230
Rotation Clockwise/Counterclockwise
RPM 3450
Service Factor 1.75
Shaft Diameter 0.63″
Speed 3450
Starting Method
