0.33HP 1PH 56 4P DP 2spd 1725 SpP 115V

Description

Product Information

Brand Leeson
Mfr # H173
Wright’s # LSN H173
Country of Origin MEX

Specifications

C Dim 10.88″
Electrical Type Split Phase
Enclosure DP
Full Load Efficiency 56.5
Frame 56
Frequency 60 Hz
HP 0.33 HP
HP2 1/3 HP
Insulation Class B
kW 0.25kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 2
Overload Protection No Protection
Phase 1
Rated Current 5.7,3.2
Rated Voltage 115
Rotation Counterclockwise/Clockwise
RPM 1725
Service Factor 1.35
Shaft Diameter 0.63″
Speed 1725,1140
Starting Method
