0.33HP 1PH 56 4P DP 1725 115/208-230V AOL

Description

Product Information

Brand Leeson
Mfr # C216
Wright’s # LSN C216
Country of Origin MEX

Specifications

C Dim 10.32″
Electrical Type Capacitor Start Induction Run
Enclosure DP
Full Load Efficiency 62
Frame 56
Frequency 60 Hz
HP 0.33 HP
HP2 1/3 HP
Insulation Class B
kW 0.25kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 6.0,3.2-3.0
Rated Voltage 115/208-230
Rotation Counterclockwise/Clockwise
RPM 1725
Service Factor 1.35
Shaft Diameter 0.63″
Speed 1725/1425
Starting Method
