0.33HP 1PH 48Z 6P OAO 3spd 1075 PSC 208-230V AOL
Description
Product Information
Brand Leeson
Mfr # X003
Wright’s # LSN X003
Country of Origin MEX
Specifications
C Dim 9.75″
Electrical Type Permanent Split Capacitor
Enclosure OAO
Full Load Efficiency 59.5
Frame 48Z
Frequency 60 Hz
HP 0.33 HP
HP2 1/3 HP
Insulation Class B
kW 0.25kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Ring – Extended Studs
Number of Poles 6
Number of Speeds 3
Overload Protection Automatic
Phase 1
Rated Current 3.3-3.3
Rated Voltage 208-230
Rotation Selective Counterclockwise
RPM 1075
Service Factor 1
Shaft Diameter 0.5″
Speed 1075
Starting Method
