0.33HP 1PH 48Z 4P OAO 3spd 1625 PSC 115V AOL

Description

Product Information

Brand Leeson
Mfr # X015
Wright’s # LSN X015
Country of Origin MEX

Specifications

C Dim 9.75″
Electrical Type Permanent Split Capacitor
Enclosure OAO
Full Load Efficiency 55
Frame 48Z
Frequency 60 Hz
HP 0.33 HP
HP2 1/3 HP
Insulation Class B
kW 0.25kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Ring – Extended Studs
Number of Poles 4
Number of Speeds 3
Overload Protection Automatic
Phase 1
Rated Current 4.0
Rated Voltage 115
Rotation Selective Counterclockwise
RPM 1625
Service Factor 1
Shaft Diameter 0.5″
Speed 1625
Starting Method
